Description
8~13 bit Vertical Resolution
Module Extensions
let’s take a look at the product hardware interface for extensions: The open DE-15 hardware interface can provide digital power as well as analog power, GPIO ports and analog input channels as shown below. This interface an be used as a standard access for signal generator modules or logic analyzer modules. Although these two modules can be plug and play in frequent use, it is recommended to connect the module after the device is powered off.
It can also be DIY a function module as shown in the figure below, and also access the device through the DE-15 interface.
Package List:
1 x Oscilloscope+Logic Module
2 x Probe
1 x USB Connector Cable
1 x Logic Cable
